32 E-flite Hawker Sea Fury 400 ARF Assembly Manual
 9. Thread the clevis back on the pushrod wire. Connect
the clevis to the elevator control horn.
 10. With the radio system on, adjust the position of the
clevis so the elevator is parallel to the stabilizer.
Linkage Installation for Optional Rudder
The next three steps cover the installation of the linkage
for the optional rudder. Skip to the next section if you are
not using the optional rudder.
 11. Remove the clevis from the 13 9 / 16
-inch (345mm)
pushrod. Slide the pushrod into the preinstalled tube
in the fuselage. Connect the bend in the pushrod to
the rudder servo horn. Position the horn so the angle
between it and the pushrod wire is 90 degrees. Secure
the horn to the servo.
