3 E-flite Hawker Sea Fury 400 ARF Assembly Manual
Using the Manual
This manual is divided into sections to help make assembly
easier to understand, and to provide breaks between each
major section. In addition, check boxes have been placed next
to each step to keep track of its completion. Steps with a single
circle () are performed once, while steps with two circles (
 ) indicate that the step will require repeating, such as for a
right or left wing panel, two servos, etc.
Remember to take your time and follow the directions.
Contents of Kit/Parts Layout
Large Parts:
EFL6055 Cowling
EFL6059 Spinner
EFL6060 Retract Set
EFL6061 Straight Wire Struts for Retracts
EFL6062 Bent Wire Struts for Fixed Gear
EFL6063 Fixed Landing Gear Set
Required Radio Equipment
You will need a minimum 3-channel transmitter, crystals, receiver,
and three sub-micro servos. You can choose to purchase a
complete radio system. If you are using an existing transmitter,
just purchase the other required equipment separately. We
recommend the crystal-free, interference-free Spektrum ™ DX6i
2.4GHz DSM ® 6-channel system. If using your own transmitter,
we recommend the E-flite ® S75 Sub-Micro Servos.
If you own the Spektrum DX6i radio, just add the AR6100E
DSM2 ™ 6-channel receiver and three (to six) of our E-flite S75
Sub-Micro Servos.
Complete Radio System
SPM6600 DX6i DSM 6CH system
Or Purchase Separately
JRPR720UL UltraLite 7-Channel ScanSelect ™
FM Receiver (72MHz)
JRP790UL UltraLite 7-Channel ScanSelect
PCM Receiver (72MHz)
Or
SPMAR6100E AR6100E DSM2 6-Channel Receiver
UltraLite (for DX6i on DX7)
And
EFLRS75 7.5-Gram Sub-Micro Servo (3–6)
EFLREX6L 6-inch Servo Extension, Lightweight (3)
EFLREX9L 9-inch Servo Extension, Lightweight (2)
(Optional Retracts)
EFLRYH3 3-inch Y-Harness, Lightweight
(2 required without computer radio)
