24 E-flite Hawker Sea Fury 400 ARF Assembly Manual
Tail Gear Installation - Fixed Rudder
Required Parts
Tail wheel collar w/setscrew Tail wheel
Wheel spacer Wheel axle cap
Fixed tail gear wire
Required Tools and Adhesives
Hex wrench: 1.5mm Foam-safe CA
Note: If you will be installing the operational rudder, skip
to the next section of the manual.
 1. Slide the tail wheel collar onto the tail wheel bearing.
Align the setscrew with the notch in the bearing.
 2. Slide the fixed gear tail wire into the bearing, then use
a 1.5mm hex wrench to tighten the setscrew. The wire
has a flat area for the setscrew to be tightened onto.
 3. Slide the wheel spacer onto the tail gear wire.
