2 table iia – Watts Autotrol Magnum (CV+ Series) User Manual
Page 39
35
6.2 Table IIA
Level II Program Values - 962 Single Twin or Triple Parallel Tank Softener or Dealkalizer (P17=0)
Note: This programming sheet is for use with controls
manufactured after 09 Aug 2000.
Parameter
Description of
Program Values
Range of Values
Min.
Increment
Factory
Value
Units of Measure
Notes
P1
Day of Week and
Time of day
(1-7) 1:00 - 12:59
AM or PM
Metric (1-7)
0:00 - 23:59
(1 day)
1 minute
None
Hour
Minute
Range depends on value selected for
P13. For day of week SUN=1, MON=2,
TUE=3, WED=4, THU=5, FRI=6, SAT=7.
This is the left most digit on the display.
P2
Time of day to start
regeneration
1:00 - 12:59
AM or PM
00:00 - 23:59
1
None
Hour
Minute
Range depends on value selected for
P13 Use only if P15 = 0 or 1
P3
Hardness of water
3-250
30-2500
1
10
0
0
Grains per gallon
ppm
Unit of measure depends on value
selected for P12
P4
Salt amount
5 – 1250
2 - 500
5
2
10
4
Pounds
Kilograms
Unit of measure and factory value
depends on value selected for P12
P5
Capacity of unit
1-2600
0.1-260.0
1
0.1
0
0
Kilograins
Kilograms
Unit of measure depends on value
selected for P12
P6
Refill controller
2 - 99
1
0
Selected from chart in Performance Data
P7
Brine draw rate
2 - 99
1
0
Selected from chart in Performance Data
P9
Backwash time
4 - 30
1
14
Minutes
May be adjusted for application
P10
Rinse time
7 - 125
1
40
Minutes
May be adjusted for application
P11
Purge time
2 - 19
1
4
Minutes
May be adjusted for application
P12
Units of measure
0 - 1
1
0
0 = US, 1 = Metric
P13
Clock mode
0 - 1
1
0
0 = 12 hour clock, 1 = 24 hour clock
P14
Calendar override
0 - 30
1
0
Days
0 = no calendar override
P15
Reserve Type
0 - 3
1
0
0=Variable Reserve, 1=Fixed Reserve
2=Variable Reserve with immediate
regeneration , 3=Fixed Reserve with
immediate regeneration
P16
Initial average
usage or fixed
reserve
0 - 70
1
30
Percent of Total
capacity
P17
Operation type
0 - 2
1
0
0 = Single or Parallel
P18
Salt/Capacity
Change Lock Out
0 - 1
1
0
0 = none, 1 = Salt /Capacity Change
Locked Out
P19
Flow Sensor select
0
0 = Magnum IT NHWB, 1 = 1.0" Autotrol
turbine, 2 = 2.0” Autotrol turbine, 3 =
User defined K-factor, 4 = User defined
pulse equivalent, 5 = Magnum IT HWB
P20
K-factor or Pulse
equivalent
0.01 - 255.00
.01
0.01
Number used for Meter K-factor or Pulse
equivalent
P21
Remote
Regeneration
Switch Delay
1 - 254
1
60
Seconds
Time remote switch must be active to
start a regeneration.
P22
Factory Use Only
– DO NOT
CHANGE
99
Do not change
