2 Installation
791 VA Detector
14
2.5 Analog output connections
The 791 VA Detector has two analog output sockets: 22 (live) and 23
(common) for connecting a chart recorder of a different data recording
instrument. The full-scale deflection range for the analog output (1 V or
10 mV) can be set with switch 21; the polarity can be changed with
switch 20 (see section 3.3).
The 6.2115.010 Cable can be used for connecting recorders with ba-
nana plug connections; the 6.2115.060 Cable can be used for connect-
ing data recording instruments with terminals.
