￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 3 Installation
864 Robotic Balance Sample Processor ￭￭￭￭￭￭￭￭ 23
Tower 2
Configure the positions for tower 2:
1 Open the tower configuration
￭ Click the tab Tower 2.
2 Enter the configuration data
￭ Enter the following settings:
– Max. stroke path 171 mm
– Swing position 0 mm
– External position 1, angle 120.5°
– External position 1, work position 151 mm
3.5.3 Configuring rack data
On the rack, reserved positions for rinsing beakers are necessary. These
can be defined in the rack data.
Rack data
1 Open the dialog window
￭ Click the tab Rack.
￭ Click the button Rack data.
The dialog window of the rack data is opened.
2 Define special beaker 1
￭ Click Special beakers.
￭ Select the first line for the Special beaker 1 and press [Edit].
￭ Enter the following data:
– Rack position 57
– Work position Tower 2 170 mm
￭ Close the dialog window with [OK].
3 Define special beaker 2
￭ Select the second line for the Special beaker 2 and press [Edit].
￭ Enter the following data:
– Rack position 58
– Work position Tower 2 170 mm
￭ Close the dialog window with [OK].
