112 • Appendix A. Specifications
R-Series Data Center Products User’s Guide
R4300 Chassis
F6150–160 Fiber Transceiver
BIOS
•
Phoenix® BIOS
•
Supports PXE, Secure Agent,
Multiprobe, PnP, Phoenix Phlash &
Multikey
•
AMI® BIOS
•
Supports PXE
•
AMI BIOS
•
Supports PXE
Dimensions
•
4.7” (H) x 23.5” (L) x 1.9” (W)
•
Weight: 6 lbs.
•
4.7” (H) x 23.5” (L) x 4.7” (W)
•
Weight: 10-13 lbs. depending on
configuration
•
Size: 4.7” (H) x 23.5” (D) x 1.9” (W)
•
Weight: 4 to 5 lbs, depending on
configuration
Environmental
•
Stationary office, 0–35
° C
•
Stationary office, 0–35
° C
•
Stationary office, 0–35
° C
Table 2 R4300 Chassis Specifications
Connections
•
8-slot chassis
•
Hot-swappable Management, Connect, and Network modules provide Ethernet, C/Port,
and USB connections
•
Backwards compatible with Direct Connect or Blade Switching BackPack
•
Fit 14 chassis (112 PC blades) in a single 42U rack or cabinet
•
Four variable-speed exhaust fans located in rear
•
Rear power connection
Dimensions
•
3U (5.25-inch high, standard 19-inch rack width)
•
17.0 inches (w) x 5.25 inches (h) x 29.8inches (d)
Power Input
•
Dual AC input
•
100–240 VAC, 50/60 Hz, dual redundant PSUs
•
Power supplied to each individual PC blade slot
•
1440 W power required per full chassis (max.)
•
12 Amps current required per full chassis (at 120 VAC) (max.)
AC Input Fuse
•
T15A, 250V (5x20 mm slow-acting 15 amp fuse)
R4300 CAUTION
DOUBLE POLE/NEUTRAL FUSING
Weight
•
42 lbs empty, 85 lbs with 8 PC blades
Environmental
•
Rack mounted, 0–35º Celsius (C)
Table 3 Fiber Transceiver Specifications
Connector I/O
•
16 RJ-45 copper inputs and 16 MT-RJ dual fiber outputs
Fiber Type
•
62.5 micron, multi-mode, straight-through connection fiber
Max. Distance
•
60/62.5 micron: 2000 meters (6562 feet) for each C/Port connection
