R-Series Data Center Products User’s Guide Chassis and Blade Installation • 63
two or more DVI-I displays to your PCoIP client. Perform the following steps to
disable the default VGA display and enable one or more additional DVI displays.
1. Connect one or more additional DVI displays to your PCoIP client.
2. Right-click an empty area on the desktop.
3. Select ScreenToys from the right-click menu to display the Device Management
dialog box.
4. From the Monitor menu, select the VGA display. The icons in the Display
Devices area refresh to reflect your selection.
5. From the Display Devices area, clear the VGA checkbox to disable the monitor
and then click Apply All.
Video Resolution
The ClearView Quadro4 video driver that comes pre-installed on ClearCube PC
blades supports video resolutions as high as 1280 x 1024. If you require video
resolutions greater than this, you need to uninstall the ClearView Quadro4 driver from
the blade and install the standard, high resolution Quadro4 video driver from the
ClearCube web site at
http://www.clearcube.com/support/ . Do not use drivers
downloaded directly from the NVIDIA web site, as they have not been validated to
work properly with a ClearCube system.
Changing CMOS Settings
You can change CMOS and BIOS settings using the BIOS setup utility. To access the
utility, power on a blade and press the F2 key when the ClearCube splash screen
appears (the splash screen should provide prompts about additional options and
corresponding keys to press).
Display Devices
Area
Monitor Menu
