R-Series Data Center Products User’s Guide Chassis and Blade Installation • 61
To connect C/Ports to a dual-slot blade, use only the even-numbered C/Port
connectors 2, 4, 6, or 8, relative to those slot pairs. The odd-numbered C/Port
connections on the chassis are not connected to dual-slot blades.
R3080D Video Options and Ethernet Port Behavior
The R3080D provide two Ethernet ports that correspond to the primary and secondary
Ethernet jacks on the rear of a chassis. Your graphics card configuration determines
the behavior of the blade’s Ethernet ports.
• Quadro4 PCI-Express card and integrated graphics (with i5-660 processor):
– Primary port: Gigabit Ethernet
– Secondary port: Gigabit Ethernet
• V5220 Dual Host card:
– Primary port: Gigabit Ethernet
– Secondary port: PCoIP communication to PCoIP zero clients
R1350 Video Options and Ethernet Port Behavior
The R1350 provide two Ethernet ports that correspond to the primary and secondary
Ethernet jacks on a chassis. Your graphics card configuration determines the behavior
of the blade’s Ethernet ports.
• Quadro4 PCI-Express card and GMA 950 integrated graphics:
– Primary port: Gigabit Ethernet
– Secondary port: 10/100 Ethernet
• V5120 Dual Host card:
– Primary port: Gigabit Ethernet
– Secondary port: PCoIP communication to PCoIP zero clients
Using USB 2.0 Capability on the R3040S and R1350
The R3040S and R1350 provide two USB 2.0 ports: one on the front of the Blade and
one on the back apron of the R4300 when the blade has a 44-pin interposer installed.
The 30-pin interposer does not bring the USB 2.0 signals onto the R4300 signal
backplane.
The USB port on the R1350 connects to the corresponding USB port on the R4300.
NOTE: Always connect cables to the primary Ethernet port first.
NOTE: In an R4200 chassis only the primary port is connected.
NOTE: Always connect cables to the primary Ethernet port first.
NOTE: In an R4200 chassis only the primary port is connected.
