R-Series Data Center Products User’s Guide Chassis and Blade Installation • 53
each RMC with a different IP address. This allows you to log in to each group of
chassis independently.
Default RMC Settings: IP Address: 192.168.1.251
Gateway: 192.168.1.1
Network: 192.168.1.0
Netmask: 255.255.255.0
Changing the IP Address of the RMC
To change the IP address on an RMC, do the following:
1. From any computer on the network connected to the RMC, open a telnet session
to log into the RMC using the default RMC IP address of 192.168.1.251. If your
network settings are incompatible with the RMC’s default settings, then you need
to select one computer (notebook, blade, or other PC) that you can use to program
the RMC. Set this computer’s network settings to be compatible with the RMC
default settings and connect its network port directly to the CONTROL IN port
on the R4200 using the provided cross-over cable. To telnet into the RMC from a
DOS prompt, type:
H:\>Telnet 192.168.1.251
The result should be:
Password:
2. Type clearcube as the default password. For example:
Password: clearcube
The result should be:
RMC Configuration
1. IP address: 192.168.1.251
2. Gateway: 192.168.1.1
3. Network: 192.168.1.0
4. Netmask: 255.255.255.0
5. Password: clearcube
6. Exit
3. From the list of options, select 1 to change the IP address. For example:
>1
NOTE
Every primary R4200 chassis with an RMC installed is shipped
with the same default network settings. If you are using multiple
Chassis groups, you must configure new IP addresses per the
instructions below to avoid a conflict.
NOTE You will not see any letters as you type the password.
