30 • Chassis and Blade Installation
R-Series Data Center Products User’s Guide
STATUS
Blue
•
C/Port connection status
— Green = good digital link to blade
— Red = bad digital link to blade
— Off = no blade
•
USB connection status
— Green = USB available
— Red = USB not available
— Off = no blade
•
Network connection status
— Green = good network connection
— Off = no network connection, or no blade
C/PORTS
Blue
Blue LED that, when lit, indicates that the Status LEDs above the Management Bay
module are displaying status for the C/Port connections. Not populated on ACM. The
Status LEDs display these conditions for C/Ports:
•
Green = good digital link to blade
•
Red = bad digital link to blade
•
Off = no blade
USB
Blue
Blue LED that, when lit, indicates that the Status LEDs above the Management Bay
module are displaying status for the USB connections. The Status LEDs display these
conditions for USB connections:
•
Green = USB available
•
Red = USB not available
•
Off = no blade
