48 • Chassis and Blade Installation R-Series Data Center Products User’s Guide
• Do not use Mixed Mode (connecting a mix of R4300s, BSBPs, and/or DCBPs) for
connecting your Control Chain.
• Use an RMC to manage only BSBP- and DCBP-equipped chassis.
• Configure RMCs using Telnet.
• Use an RMM to manage new R4300 chassis, and BSBP- and DCBP-equipped
chassis that do not contain an RMC.
• Configure RMMs using Sentral.
• If your Control Chain contains a mix of R4300s, BSBPs, and/or DCBPs and you
have an RMC installed in a BSBP or DCBP, that RMC is always the Primary and
it does not provide access to all of the functions of the R4300.
• If you add BSBPs or DCBPs to a Control Chain that contains one or more RMMs,
exchange BackPacks with RMCs installed for BackPacks that do not have RMCs.
Configuring the RMM
ClearCube recommends using Sentral as the primary configuration tool for RMMs.
See the Sentral Administrator’s Guide for complete information. The RMM can also
be configured with Telnet. To configure an RMM using Telnet, do the following:
1. Open a command window and enter
telnet RMM_IPAddress
where RMM_IPAddress is the IP address of the RMM to be configured.
2. Enter the password for the RMM (no characters are echoed), and type
cfg all
NOTE
Maintain the default setting of JP1 on the RMM
(auto-negotiation enabled). See Figure 28 on page 47. Change
this setting only at the recommendation of ClearCube Technical
Support or a ClearCube Support Engineer.
