Sentral Quick Start Guide
20 Rev F 2.2.08.06.2014
10.13 Label Display in Chassis View
The Staggered Labels option specifies how C/Port, Host, and I/Port labels are displayed in chassis
graphical views (for example, in the C/Ports – Switching screen.
Figure 11 below shows staggered C/Port
labels.
Figure 11. Staggered view of C/Port labels in R-Series chassis view
10.14 VMware View Connection Server Settings
Sentral can push out the IP address and settings of a VMware View server (such as port number, SSL
setting, and auto-connect options). From the Discovery Options screen, select View Connection Server
and then click Discover to push this information to zero clients.
Figure 12. Using discovery to push VMware View information to devices
