Brandmotion 1008-6509-V1 - Manual

6509 Instructions 6-18-12 F series (1).doc 1 of 23
Rear Vision System – Tailgate Emblem Camera Aftermarket Display
2009-Current Ford F-150 and 2010-Current Super Duty
(Kit part number 1008-6509)
Kit Contents: Tools Required:
Tailgate Emblem Mount with Camera
Chassis Harness with RCA (Note: In some cases a
RCA extension may be required to connect to
your aftermarket display.)
1 bag containing: Ford Emblem
1 bag containing
2 Tailgate emblem retainers
2 Mounting Screws
1 bag containing:
25 Wire Ties
Z-Tech (in a white bottle)
1 bag containing:
3 Templates (along with these instructions)
T30 Torx Driver
7mm, 8mm, and 10mm Sockets
Flat Head Screwdriver
Plastic Trim Removal tool
Drill Bit and small Flat File (if needed)
1 inch and 1¾ inch Center Hole Saws
Soldering Iron
Small brush
Round file (if needed)
Deburring Tool
NOTE: We strive to provide accurate and up-to-date installation instructions. The latest full color
instructions, as well as an installation video by viewing the relevant portions of the full mirror kit
(part number 1008-9520) can be accessed at www.brandmotion.com
PRE-INSTALLATION VEHICLE CHECKLIST
Before beginning, determine how the vehicle is equipped and check appropriate boxes:
Determine whether the vehicle has an opening in the center of pickup bed close to opposite of the opening in the
bottom of the tailgate.
□
Yes, skip Section 2.
□
No, tailgate must be removed to drill an opening for the camera harness (refer to Section 2).
Determine whether the vehicle has the required three mounting holes behind the existing tailgate emblem. Refer to
Steps 1 & 2 to remove inner tailgate panel, and use supplied 1008-9100-03 template to confirm whether the required
holes are present in the panel.
□
No, use supplied 1008-9100-03 template to position the holes to drill and/or cut the tailgate. If you do not wish
to cut the tailgate, Brandmotion offers tailgate handle camera kits (1008-6501, black handle, and 1008-6502,
chrome handle) that do not require cutting.
□
Yes, proceed to Section 3.
□
Check kit contents are complete against the list above.
