233 Publication IASIMP-QS010B-EN-P - October 2009 233
Chapter
5
Program the Packaged Controller
Topic Page
Programming Specifications Quick Reference 233
Program the Controller 234
Tasks 234
Programs and Equipment Phases 234
Trends 235
Monitoring Controller Status 235
Quick Reference - Programming Specifications of the CompactLogix Packaged Controllers
Program Attribute Value For More Information See
Memory size 512 KB Logix5000 Controllers Execution Time and Memory Use Reference
Manual, publication
1756-RM087
Programming Languages
•
Ladder Diagram
•
Function Block
•
Structured Text
•
Sequential Function Chart
Logix5000 Controllers Common Procedures Programming Manual,
publication
1756-PM001
Tasks, total available 3
•
Tasks on page 234
•
Logix5000 Controllers Design Considerations Reference Manual,
publication
1756-RM094
•
Logix5000 Controllers Common Procedures Programming
Manual, publication
1756-PM001
Programs or equipment phases,
total available 16 per task
•
Programs and Equipment Phases on page 234
•
Logix5000 Controllers Common Procedures Programming
Manual, publication
1756-PM001
Trends, total available 1
•
Trends on page 235
•
Logix5000 Controllers Quick Start, publication 1756-QS001
TCP connections available 8 Maximum Ethernet Interface Connections on page 160
CIP connections available 32 Maximum Ethernet Interface Connections on page 160
Virtual Axis Limit 4 Formerly 2 virtual axis
PIDE autotune Supported
•
Program attribute = PIDE
autotune
•
Value-enabled
RSLogix 5000 PIDE Autotuner - Getting Results, publication
PIDE-GR001
