Chapter 7 Optional - Configuration of the DeviceNet Network
Additional Resources
These publications are available for viewing or electronic download at http://literature.rockwellautomation.com .
Resource Description
1769-SDN Compact I/O DeviceNet Scanner
Module Installation Instructions, publication
1769-IN060
Provides information about installing the 1769-SDN module and technical
specifications.
DeviceNet Modules in Logix5000 Control
Systems, publication
DNET-UM004
Provides details regarding the installation, configuration, and operation of DeviceNet
modules.
POINT I/O DeciveNet Adapter User Manual,
publication
1734-UM002
Provides information related to the use of 1734-ADN and 1734-ADNX modules on a
DeviceNet network.
DeviceNet Media Design and Installation
Guide, publication
DNET-UM072
Provides comprehensive information about planning, designing, and installing
components of a DeviceNet network.
CompactLogix System Quick Start, publication
IASIMP-QS001
Provides procedural information related to the use of 1769-L3x CompactLogix
controllers, including detailed explanations for use of a 1734-ADN adapter and
PowerFlex 40 drive with a DeviceNet network. The procedures in this publication are
also applicable to the use of a CompactLogix packaged controller.
Chapter 2 of the user manual, Network
Communication ,on page 157
Describes the DeviceNet module and software that are compatible for use with the
packaged controllers.
