Parts List This table lists the hardware used in this quick start. The hardware you need
depends on the options and examples you choose to complete. Specific
hardware requirements are listed at the beginning of each chapter.
Hardware Used in This Quick Start

Quantity Cat. No. Description
General Configuration
1 1769-L23E-QB1B,
1769-L23E-QBFC1B, or
1769-L23-QBFC1B CompactLogix Packaged Controller
1 1769-ECR Compact I/O Right End Cap/Terminator (included with packaged controller)
1
1734-IB4
(1) POINT I/O 4 Sink Input Module
1
1734-OB4E
(2) POINT I/O 4 Protected Output Module
1
1734-OE2C
(1) POINT I/O 2 Current Output Analog Module
1-3
1734-TB
(3) Wiring Base w/ Removable IEC Screw Terminals
1 1794-PS13 FLEX I/O 85…264V AC to 24V DC 1.3 A Power Supply
1 22B-V2P3N104 PowerFlex 40 Drive
1 22B-CCB PowerFlex 40 Communication Adapter Cover
1 2711P-T6C20A PanelView Plus 6-inch Color Keypad Terminal with EtherNet/IP and RS-232 Networks
1 1794-PS3 or
2711P-RSACDIN Flex I/O Power Supply or Other General-use Power Supply to supply 70 W DC power to
PanelView Plus (if DC power is required for your terminal)
2 1756-CP3 RS-232 Cable
1 2706-NC13 PanelView Plus Serial Cable
2…3 N/A DIN Rail (steel not aluminum)
1 1606-XLS80E DC Power Supply
EtherNet/IP Configuration
1 1734-AENT POINT I/O EtherNet/IP Adapter
1 22-COMM-E EtherNet/IP Adapter for Use With the PowerFlex 40 Drive
1 1783-EMS08T Stratix 6000 Ethernet Switch (recommended), Stratix 2000 Ethernet Switch (for
applications without remote I/O), or other Ethernet Switch
6 1585J-M8
Industrial-grade Ethernet Cables
(5)
or Other Standard Ethernet Cables
Serial Configuration
1 1756-CP3 RS-232 cable
1 2706-NC13 Point-to-point RS-232 Cable (required with 1769-L23-QBFC1B packaged controllers,
optional with 1769-L23E packaged controllers)
