125
Publication IASIMP-QS010B-EN-P - October 2009
125
Chapter
7
Optional - Configuration of the DeviceNet Network
This chapter describes some of the tasks required to set-up and configure a DeviceNet
network with your packaged controller.
The examples shown in this quick start use an example DeviceNet network configuration as
depicted in configuration Option 2, on
.
Before You Begin
•
Prepare the computer, see
.
•
Assemble and configure components of the DeviceNet network. This includes the
creation of a main DeviceNet configuration file in RSNetWorx for DeviceNet.
What You Need
•
Power supply and tap for the DeviceNet network
(this example uses the 1606-XLDNET8 and a KwikLink power tap module)
•
1769-SDN DeviceNet scanner
•
RSNetWorx for DeviceNet software
•
DeviceNet Tag Generator utility (installed with RSLogix 5000 software)
IMPORTANT
This chapter does not provide complete details for the installation and
configuration of a DeviceNet network.
If you need additional information about configuring your DeviceNet network or
using other devices, such as the 1734-ADN adapter, with the packaged controllers,
see the
at the end of this chapter.
