Accessories E-3
E.2 EMC Line Filters
Table E.2 – EMC Line Filters
Drive Ratings
S Type Filter
Model Number 1
1 This filter is suitable for use with a cable length of at least 10 meters
(33 feet) for Class A and 1 meter for Class B environments.
L Type Filter
Model Number 6
6 This filter is suitable for use with a cable length of at least 100 meters
for Class A and 5 meters for Class B environments.
Input Voltage kW HP
120V 50/60 Hz
1-Phase 0.2 0.25 – 6MDF-010AL
0.4 0.5 – 6MDF-010AL
0.75 1.0 – 6MDF-018BL
1.1 1.5 – 6MDF-025CL
240V 50/60 Hz
1-Phase 0.2 0.25 2
2 These ratings can be ordered with internal “S Type” filters.
6MDF-010AL
0.4 0.5 3
3 These ratings can be ordered with internal “S Type” filters.
6MDF-010AL
0.75 1.0 2 6MDF-010AL
1.5 2.0 2 6MDF-018BL
240V 50/60 Hz
3-Phase 0.2 0.25 6MDF-021BS 4
4 Filter must be Series B.
6MDF-9P5AL
0.4 0.5 6MDF-021BS 5
5 Filter must be Series B.
6MDF-9P5AL
0.75 1.0 6MDF-021BS 3 6MDF-9P5AL
1.5 2.0 6MDF-021BS 3 6MDF-9P5AL
2.2 3.0 6MDF-021BS 3 6MDF-021BL
3.7 5.0 6MDF-021BS 3 6MDF-021BL
480V 50/60 Hz
3-Phase 0.4 0.5 6MDF-012BS 6MDF-5P7AL
0.75 1.0 6MDF-012BS 6MDF-5P7AL
1.5 2.0 6MDF-012BS 6MDF-5P7AL
2.2 3.0 6MDF-012BS 6MDF-012BL
3.7 5.0 6MDF-012BS 6MDF-012BL
