B-16, Flexpak 3000 drive – Rockwell Automation FlexPak 3000 DC Drive Version 4.3 User Manual
Page 88
B-16
FlexPak 3000 DC Drive Hardware Reference Version 4.3
Figure B.14 – Typical FlexPak 3000 Wiring for EMC Compliance with Optional Dynamic Braking Kit Installed
GROUNDING BUS BAR
U
V
W
PE
A1
F1
A2
F2
G
R
O
UNDI
NG
BUS
BAR
AC MAI
N
S
FI
LTE
R
AC MAINS INDUCTOR
REGULATOR BOARD
CONVENIENCE TERMINALS
ENCLOSURE
DISCONNECT
DC MOTOR
ARMATURE AND
FIELD CONDUIT
TACHOMETER
CONDUIT
CONTROL
CONDUIT
BRAIDED STRAP
FROM ENCLOSURE
SKIN AND DOOR
TO GROUND BAR
BRAIDED
STRAP
FLEXPAK 3000
DRIVE
DYNAMIC
BRAKING
CONTACTOR
DYNAMIC BRAKING EXPANDED METAL
RESISTOR ENCLOSURE
CONT
XFMR
FUSE
F2 F1 A1 A2
183
181 182
REGULATOR BOARD TERMINALS
AC POWER
ENTRY
