Rockwell Automation FlexPak 3000 DC Drive Version 4.3 User Manual
Page 70

A-4
FlexPak 3000 DC Drive Hardware Reference Version 4.3
Table A.7 – Power Ratings
1
(380/415 VAC)
1
When applying FlexPak 3000 drives to a power distribution system with KVA capacity in excess of 5 times the smallest drive rating, the
use of an isolation transformer or line reactors of similar impedance is required. Note also that the drives are designed for a maximum of
three units per transformer.
Unit
Type
Input
Voltage
(VAC)
Full Load
Rated RMS
AC Line
Current
(Amperes)
Full Load
Rated DC
Armature
Current
(Amperes)
Rated
Field
Current
(Amperes)
Maximum
Symmetrical
AC Fault
Current
(Amperes)
Min.
Source
KVA
Reference HP
@ 460 VAC
Input
2
2
This drive is not rated for 460 VAC input. Horsepower is provided for reference only and should not be used for rating or scaling purposes.
7 A
380/415
10
7
10
5000
4/5
3
29 A
380/415
26
29
10
5000
16/18
15
55 A
380/415
48
55
10
5000
33/36
30
110 A
380/415
94
110
15
10000
62/68
60
265 A
380/415
226
265
15
25000
145/157
150
Table A.8 – Logic Inputs
Input Voltage
+24 VDC
Turn On Voltage
+8 VDC
Turn off Current
0.5 mA
Common
All input circuits have the same common.
Table A.9 – Logic Outputs
Operating Voltage
250 VAC maximum
30 VDC maximum
Switching Current
2 A maximum resistive
1 A maximum inductive
