B-4 FlexPak 3000 DC Drive Hardware Reference Version 4.3
B.2.4 Selecting an Operator Control Station
If an operator control station is connected to the drive, its enclosure must be
conductive metal. The enclosure cover must be bonded to an internal ground point
with a braided strap across the hinge. Standard industrial operator devices, such as
pushbuttons, switches, and meters, can be used.
Table B.2 – AC Mains Filter Model Numbers for 3 to 300 HP @ 460 VAC FlexPak 3000 Drives
HP
Rating
AC Full
Load
Amps
Minimum
Inductance
(in microhenries
(
µ
H))
AC Mains Filter
Model Number
AC Mains
Inductor
3 10 1680 3DF4353 608895-63H
5 12 1400 3DF4353 608895-63H
7.5 15 1125 3DF4353 608895-63K
10 18 1000 3DF4354 608895-63K
15 24 700 3DF4354 608895-63M
20 31 550 3DF4355 608895-63P
25 39 430 3DF4355 608895-63P
30 45 375 3DF4355 608895-63R
40 60 270 3DF4357 608895-63W
50 74 225 3DF4357 608895-63W
60 86 195 3DF4357 608895-63Y
75 110 150 3DF4359 608895-63AA
100 143 120 3DF4359 608895-63AC
125 177 95 3DF4359 608895-63AE
150 213 80 3DF4359 608895-63AG
200 281 60 3DF4359 608895-63AK
250 351 48 Two 3DF4359
filters connected
in parallel
608895-63AN
300 421 40 608895-63AR
