Rockwell Automation Publication ENET-IN002F-EN-P - January 2014

Chapter 3 Install a 1769 EtherNet/IP Adapter

Use DHCP Software

Dynamic Host Configuration Protocol (DHCP) software automatically assigns
IP addresses to client stations logging onto a TCP/IP network. DHCP is based
on BOOTP and maintains some backward compatibility. The main difference is
that BOOTP allows for manual configuration (static), while DHCP allows for
both static and dynamic allocation of network addresses and configurations to
newly attached modules.

Be cautious when using DHCP software to configure a module. A BOOTP
client, such as the EtherNet/IP adapters, can start from a DHCP server only if
the DHCP server is specifically written to also handle BOOTP queries. This is
specific to the DHCP software package used. Consult your system administrator
to see if a DHCP package supports BOOTP commands and manual IP
allocation.

Set the Network IP Address with RSLinx or the Studio 5000
Environment

This table describes when to set the network IP address with RSLinx or the
Studio 5000 environment.

Consider these factors when you determine how to set the network IP address:

• Network isolation from or integration into the plant/enterprise network
• Network size - For large networks, isolated networks, it might be more

convenient and safer to use a BOOTP/DHCP server rather than
the Logix Designer application or RSLinx software. The BOOTP/DHCP
server also limits the possibility of assigning duplicate IP addresses.

• Company policies and procedures dealing with plant floor network

installation and maintenance

• Level of involvement by IT personnel in plant-floor network installation

and maintenance

• Type of training offered to control engineers and maintenance personnel

ATTENTION: The EtherNet/IP adapter module must be assigned a fixed
network address. The IP address of this module must not be dynamically
provided.

Failure to observe this precaution can result in unintended machine motion or
loss of process control.

Conditions

Software to Use

Page

• A BOOTP server is not available.

• The EtherNet/IP adapter is connected to another NetLinx network.

RSLinx software

The Logix Designer project is online with a controller that communicates to

or through the EtherNet/IP adapter.

Studio 5000 environment
(Logix Designer application,
version 20.00.00 or later)
