84 DeviceNet Objects
Get_Event Service Response Data Format
Event Data Format for Application Notification Event Type
Table C.23 Get_Event Service Response Data Format
Byte Name Data Type Description Semantics
1 - 8 Time Stamp LTIME The relative time of the event
occurrence. 64-bit microsecond counter
9 - 10 Event Type UINT Identifies the type of the event. 6 = Application notification
11 - 12 Event Data Format UINT Identifies the format of the event
data. This may be useful for
discriminating between different
revisions of the event data format.
For example, the format changed
from one product revision to the
next. 1 (initial revision)
13 Event Data Length USINT The number of bytes of Event
Data.
14 Event Data Array of
BYTE Event related data in format based
upon the Event Type Application Specific
See below for format for
Application Notification event.
Table C.24 Event Data Format for Application Notification Event Type
Byte Name Data Type Description Semantics
14 Event Data Array of
BYTE A more detailed Event
classification. 0 = Alarm Status Change
1 = Relay Status Change
2 = Setpoint Multiplier
Occurrence
3 = Configuration Change
Occurrence
15 MAC ID MAC ID The MAC ID of the device that
originated the Alarm or Relay
events. 0 to 63
16 Instance Number USINT The Alarm or Relay Object instance
number for Alarm or Relay events. 1 to 255
17 New Status USINT The new Alarm Status or Relay
Status value for Alarm and Relay
events. Relay Status Value
0 = Not activated
1 = Activated
Alarm Status Value
0 = Normal
1 = Alert
2 = Danger
3 = Disarm
4 = Transducer or Sensor OOR
Fault
5 = Module Fault
6 = Tachometer Fault
7 = Reserved
