Rockwell Automation 1440-RMA00-04RC XM-440 Master Relay Module - Manual (Page 26)

Rockwell Automation Publication GMSI10-UM009D-EN-P - June 2011
26 Installing the XM-440 Master Relay Module
7 No Connection
8 Relay 2 N.O. 1 Relay # 2 Normally Open contact 1
9 Relay 3 N.O. 2 Relay #3 Normally Open contact 2
10 No Connection
11 Relay 3 N.O. 1 Relay #3 Normally Open contact 1
12 Relay 4 N.O. 2 Relay #4 Normally Open contact 2
13 Relay 4 N.O. 1 Relay #4 Normally Open contact 1
14 No Connection
15 Chassis Connection to DIN rail ground spring or panel mounting hole
16 TxD PC serial port, transmit data
17 XRTN Circuit return for TxD and RxD
18 Switch RTN Switch return, Reset Relay
19 24V Out Diode-ORed output for 24V In 1 and 24V In 2
DO NOT CONNECT
20 Relay 1 Common 2 Relay #1 Common contact 2
21 Relay 1 Common 1 Relay #1 Common contact 1
22 Relay 2 Common 2 Relay #2 Common contact 2
23 No Connection
24 Relay 2 Common 1 Relay #2 Common contact 1
25 Relay 3 Common 2 Relay #3 Common contact 2
26 No Connection
27 Relay 3 Common 1 Relay #3 Common contact 1
28 Relay 4 Common 2 Relay #4 Common contact 2
29 Relay 4 Common 1 Relay #4 Common contact 1
30 No Connection
31 Chassis Connection to DIN rail ground spring or panel mounting hole
32 DNet V (+) DeviceNet bus power input, positive side (red wire)
33 CAN_High DeviceNet bus connection, high differential (white wire)
34 RxD PC serial port, receive data
35 No Connection
36 No Connection
37 No Connection
38 Relay 1 N.C. 2 Relay #1 Normally Closed contact 2
39 Relay 1 N.C. 1 Relay #1 Normally Closed contact 1
40 Relay 2 N.C. 2 Relay #2 Normally Closed contact 2
41 No Connection
Terminal Block Assignments
No. Name Description
