Rockwell Automation 1440-RMA00-04RC XM-440 Master Relay Module User Manual
Page 42
Rockwell Automation Publication GMSI10-UM009D-EN-P - June 2011
42 Configuration Parameters
Module Type
The type of XM measurement module at this node
address.
Options: XM-120
XM-120E
XM-121
XM-121A
XM-122
XM-123
XM-160
XM-161
XM-162
XM-220
XM-320
XM-360
XM-361
XM-362
None (EDS file only)
Share Option
Sets the relationship between the XM-440 (master)
and the XM measurement module (slave).
• Primary - The XM-440 is the primary master of the
XM measurement module.
• Shared - The XM-440 is sharing the XM
measurement module with a primary
master/scanner device.
Note: An XM measurement module can have only
one primary master/scanner. And, the XM
measurement module must have a primary master
before it can be shared.
Options: Primary
Shared
Node Status (XM Serial
Configuration Only)
Shows the status of all the nodes in the scanlist.
This information is useful when the XM-440 cannot
connect to a slave in the scanlist.
XM Network Node List Parameters
Parameter Name
Description
Values/Comments
