Rockwell Automation Publication GMSI10-UM009D-EN-P - June 2011
70 DeviceNet Objects
Identity Object
(Class ID 01
H
)
The Identity Object provides identification and general information about the
device.
Class Attributes
The Identity Object provides no class attributes.
Instance Attributes
Status
The Status is a 16 bit value. The following bits are implemented.
Table C.1 Identity Object Instance Attributes
Attr ID
Access
Rule
Name Data Type Default Value
1 Get Vendor ID UINT 668 = Entek
2 Get Device Type UINT 109 (Specialty I/O)
3 Get Product Code UINT 25 (0x19)
4 Get Revision:
Major
Minor
STRUCT OF
USINT
USINT
Value varies with each firmware revision
Value varies with each firmware revision
5 Get Status WORD
6 Get Serial Number UDINT
7 Get Product Name SHORT_
STRING " XM-440 Master Relay Module"
Table C.2 Identity Object Status
Bit Name Description
0 Owned TRUE indicates that the module has an owner. More
specifically, the Predefined Master/Slave Connection Set
has been allocated to a master.
1 Reserved, set to 0
2 Configured This bit is set whenever a saved configuration is
successfully loaded from non-volatile memory. This bit is
cleared whenever the default configuration is restored or
loaded.
3 Reserved, set to 0
