78 DeviceNet Objects
Instances
Table C.15 Parameter Object Instances
Instance
Read
Only
Name Data Type Valid Values Default Value
1-64 No Module Type of MAC ID n
(where n is the instance
number -1) USINT 0 = None
1 = XM-120
2 = XM-320
3 = XM-360
4 = XM-361
5 = XM-362
6 = XM-121
7 = XM-122
8 = XM-120E
9 = XM-220
10 = XM-123
11 = XM-121A
12 = XM-160
13 = XM-161
14 = XM-162 0
65-128 No Share Option for MAC ID m
(where m is the instance
number -65) BOOL 0 = Master Relay is primary
master of this slave
1 = Master Relay is sharing
this slave 0
129 No MAC ID for Relay 1, Alarm List
entry 1 USINT 0-63 = Alarm is used and
references this MAC ID
64 = Alarm entry is not used 64
130 No Alarm Number for Relay 1,
Alarm List entry 1 USINT 1-16 1
131 No MAC ID for Relay 1, Alarm List
entry 2 USINT 0-63 = Alarm is used and
references this MAC ID
64 = Alarm entry is not used 64
132 No Alarm Number for Relay 1,
Alarm List entry 2 USINT 1-16 1
... ... ... ... ... ...
511 No MAC ID for Relay 12, Alarm
List entry 16 USINT 0-63 = Alarm is used and
references this MAC ID
64 = Alarm entry is not used 64
512 No Alarm Number for Relay 12,
Alarm List entry 16 USINT 1-16 1
513 No Group 1 Member Nodes LWORD 64-bits (one bit for each
node)
1 = Group member
0 = Non-member 0
514 No Group 1 Relays to trigger from WORD 16-bits (bits 0-11 correspond
to relay instances 1-12)
1 = Trigger on relay
0 = Ignore relay
