Specifications
9-5
Characteristics
Performance
Number of Inputs:
Signal
Type
Input Voltage Range:
Input
Resistance
Input
Isolation
Input
Protection
Internal Power for Inputs
Frequency
Range
Up to 16 T6200”C”; Up to 32 T6200”D”
On/off status monitoring
0-4 V ac/dc = Off; 18-32 V ac/dc = On
4.7 k
Ω
Opto-isolated, when configured for external power
100 V transient absorbers
+24 Vdc
0-1 kHz, channels 9-16; 0-25 KHz, channels 22, 31 & 32; T6200”C”
0-1 kHz channels 1-21, 23-30; 0-25kHz, channels 22,31 &32 T6200”D”
Discrete Outputs (On/Off)
Number of Outputs:
Output
Type
Maximum Output Current
Internal Power Source
Up to 8 T6200”C”; Up to 28 T6200”D”
Open drain (collector) transistor
0.25 A continuously, 1 A momentarily, externally powered;
20 mA continuously, 100 mA momentarily, internally powered
Separate +24 Vdc regulator for each channel
Each has thermal, reverse voltage and short-circuit protection
Controller Field Connections
Signal Inputs/Outputs
Internal Term.Panel
Remote Term Panel
Power Supply
Communication
Clamping type terminal blocks for 16 AWG (1.5mm
2
)
Clamping type terminal bocks for 14 AWG (2.5mm
2
)
Clamping type terminal blocks for 16 AWG (1.5mm
2
)
RJ-45 Connector
Power Supply
Input Voltage Range
Input
Power
Redundancy
Input Voltage Ripple
18-32 Vdc
15 W, not including field devices or HMI-6200 Operator Interface
Two power sources
0.5 V maximum
Redundancy
The ICS TRIPLEX T6200 concept provides 100% redundancy with plug-in
automatic backup and bumpless transfer
