FanMaster Installation
Allen-Bradley® FanMaster™ Energy Saving Package Installation Manual -
Publication FANM-IN001B-EN-P – December, 2009 PN-65329
Installation Considerations
Consider and plan for the following when installing FanMaster for
integration with an AHU:
•
The existing BAS control supply fan start/stop signal. Two relays are
provided for interfacing to the BAS fan start/stop signal. The relay
installed in the FanMaster enclosure accommodates a 120V AC signal.
A second relay is shipped loose and accommodates a 24V AC signal. If
a signal other than 24V or 120V AC is used, you must purchase and
install the appropriate relay separately. The Allen-Bradley 700-HK
family of relays provides coil voltages from 6V AC…240V AC or 6V
DC…48V DC. More information is provided on the Allen-Bradley web
•
The existing BAS outside air damper position control signal (used with
constant ventilation option only). FanMaster provides I/O connections
for a 4…20 mA signal only. If the BAS control signal is 0…10V DC or
0…135 Ohms, a converter adapter must be purchased separately for
both the input and output signals.
•
When installing FanMaster with a Variable Frequency Drive, the
following firmware revisions must be used:
–
PowerFlex 400, v1.004 and later
–
PowerFlex 70EC v3.001 and later
–
PowerFlex 700VC v4.001 and later
–
PowerFlex 753 v1.005 and later
Installation Requirements
Power Source for FanMaster
120V AC, 10 Amp (min.) grounded service.
Tools Required for Installation
•
Variable speed drill
•
Sheet metal drill bits
•
Various screwdrivers
•
Various wrenches (open, socket and/or torque)
•
Conduit cutting and bending tools (optional, for permanent
installations)
Wiring Specifications
Important: All power, I/O and signal wiring is customer supplied.
All wire to be Stranded, copper, 600V/105 °C (194 °F) insulation.
Terminal(s) Description
Max. Wire Size Min. Wire Size
Torque
L, N
Power
10 AWG
22 AWG
1.0 N•m (9.0 lb•in)
GND
Ground
6 AWG
16 AWG
2.3 N•m (20.4 lb•in)
–
I/O and Signal
12 AWG
22 AWG
0.6…0.8 N•m (4.5…7.1 lb•in)
