Super Remote Meter Interface (RMI) Board
3.8
Installing the RMI Board in 2 to 43 Amp GV3000/SE
Bookshelf Drives
Use the procedure in this section to install the RMI board in the drives listed in table 3.8.
This procedure requires access to the right side of the drive. Remove the drive from
the panel if necessary.
Unless otherwise indicated, keep all hardware that is removed. You will need it for
reassembly. This includes screws, lock washers, and rivets.
!
ATTENTION: Only qualified electrical personnel familiar with the
construction and operation of this equipment and the hazards involved
should install, adjust, operate, or service this equipment. Read and
understand this manual and other applicable manuals in their entirety
before proceeding. Failure to observe this precaution could result in
severe bodily injury or loss of life.
ATTENTION: The drive is at line voltage when connected to incoming
AC power. Disconnect, lock out, and tag all incoming power to the drive
before performing the following procedure. Failure to observe this
precaution could result in severe bodily injury or loss of life.
ATTENTION: DC bus capacitors retain hazardous voltages after input
power has been disconnected. After disconnecting input power, wait five
minutes for the DC bus capacitors to discharge and then check the
voltage with a voltmeter to ensure the DC bus capacitors are discharged
before touching any internal components. Failure to observe this
precaution could result in severe bodily injury or loss of life.
ATTENTION: The drive contains printed circuit boards that are
static-sensitive. An anti-static wrist band should be worn by any person
who touches the drive’s components, connectors, or wiring. Erratic
machine operation and damage to, or destruction of, equipment can
result if this procedure is not followed. Failure to observe this precaution
could result in bodily injury.
Table 3.8 – Model Numbers for 2 to 43 Amp GV3000/SE Bookshelf Drives
2 to 15 Amp
24 to 30 Amp
43 Amp
31ER40xx
31ET40xx
240ER40xx
240ET40xx
430ER40xx
430ET40xx
38ER40xx
38ET40xx
300ER40xx
300ET40xx
55ER40xx
55ET40xx
85ER40xx
85ET40xx
126ER40xx
126ET40xx
150ER40xx
150ET40xx
