Front panel i/o connectors, Speaker connector, Infrared connector – Rockwell Automation 6180 Processor Board (for 6180 Industrial Computers) User Manual
Page 31
Processor Board Connectors
B–3
ОО
ОО
ОО
ОО
ОО
ОО
ОО
ОО
О
О
О
О
О
О
О
О
ОО
ОО
ОО
ОО
ОО
ОО
ОО
ОО
О
О
О
О
О
О
О
О
ПП
ПП
ПП
ПП
ПП
ПП
ПП
ПП
ПП
П
П
П
П
ПП
ПП
ПП
ПП
П
ПП
ПП
ПП
ПП
Front Panel
I/O Connectors
Speaker Connector
SPKR
IR
SLEEP PWR
HD LED
PWR LED
FAN
RST
1 2 3 4
Pin #
Signal Name
Wire Color
1
SPKR_DATA#
Black
2
On-board speaker
3
No connect
4
+5V Vcc
Red
Infrared Connector
6
SPKR
IR
SLEEP PWR
HD LED
PWR LED
FAN
RST
1 2 3 4 5
Pin #
Signal Name
1
No Connect
2
IRTX
3
Ground
4
IRRX
5
No connect
6
+5 V
Front Panel
I/O Connectors
