Page 29: Appendix
Appendix
B
Processor Board Connectors
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
О
ПП
ПП
ПП
ПП
П
П
П
ПП
ПП
ПП
ПП
ПП
ПП
ПП
ПП
ПП
П
П
ПП
ПП
ПП
П
П
ПП
ПП
ППП
ППП
COM 2
PS/2
Mouse
PS/2
Keyboard
Parallel Port
COM 1
Serial Port Connectors (COM1, COM2)
1
5
9
6
Pin #
Signal Name
1
DCD
2
Serial In
3
Serial Out
4
Data Terminal Ready (DTR)
5
GND
6
Data Set Ready (DSR)
7
Request to Send (RTS)
8
Clear to Send (CTS)
9
RI
I/O Connectors
