3–4 BIOS Setup Program
Processor Type Pentium (R) Family F1 Help
Processor Speed 166 MHz ESC Back
Cache Size 256K Enter Select
Peripheral Configuration Press Enter
"
Previous Item
Advanced Chipset Configuration Press Enter
#
Next Item
Power Management Configuration Press Enter
!
Select Menu
Plug and Play Configuration Press Enter
F5 Setup Defaults
F6 Previous Values
F10 Save & Exit
Main Advanced Security Exit
Advanced Menu
Options
Sub Menu Options AB Default Description
Processor Type Displays the CPU type (read only).
Processor Speed Displays the CPU clock speed (read only).
Cache Size
Displays the size of the secondary cache (read only). If your system
does not have an L2 cache, this item does not appear.
Configuration Mode Auto
Determines whether the peripheral configuration is set by you or if the
system handles it automatically. The options are:
•
Auto
•
Manual
When Auto is selected, the system peripherals (PCI IDE Interface,
Floppy Interface, Serial Port 1 and Serial Port 2 Addresses, Serial Port 2
IR Mode, and the Parallel Port Address) are automatically configured
during powerup and cannot be modified.
PCI IDE Interface Enabled
Enables or disables the PCI IDE hard disk interface. This option cannot
be edited if Auto was selected.
Floppy Interface Enabled
Enables or disables the floppy disk interface. This option cannot be
edited if Auto was selected.
Serial Port 1 Address COM1,3F8H,IRQ4
Selects the address of the serial port. The options are:
•
Disabled
•
COM1,3F8H,IRQ4
•
COM2,2F8H,IRQ3
•
COM3,3E8H,IRQ4
•
COM4,2E8H,IRQ3
•
COM1,3F8H,IRQ3
•
COM2,2F8H,IRQ4
•
COM3,3E8H,IRQ3
•
COM4,2E8H,IRQ4
If the Configuration Mode is set to Auto, the Setup program assigns the
first free COM port (normally COM1,3F8H) as the serial port regardless
of the serial 1 port address option.
Advanced Menu Options
