Page 28: Technical data, Appendix
Appendix
A
Technical Data
Address Range
(Decimal)
Hex
Size
Description
960K-131072K
100000-8000000
127.25M
Extended Memory
944K-959K
FE000-FFFFF
8K
Boot Block (erasable only if jumpered)
936K-943K
FD000-FDFFF
4K
ESCD (Plug and Play configuration
area)
928K-935K
FC000-FCFFF
4K
Reserved Data Area
896K-927K
E0000-FBFFF
112K
AMI System BIOS
800-895K
C8000-DFFFF
96K
Available HI DOS memory (open to
ISA and PCI bus)
640K-799K
A0000-C7FFF
160K
Off-board video memory and BIOS
639K
9FC00-9FFFF
1K
Extended BIOS Data (moveable by
GEMM, 386MAX)
512K-638K
80000-9FBFF
127K
Extended Conventional
0K-511K
00000-7FFFF
512K
Conventional
IRQ
System Resource
NMI
I/O Channel Check
0
Reserved, Interval Timer
1
Reserved, Keyboard Buffer Full
2
Reserved, Cascade Interrupt from Slave PIC
3
Serial Port 2
4
Serial Port 1
5
Parallel Port 1 (PNP0 option)
6
Floppy
7
Parallel Port 1
8
Real Time Clock
9
User Available
10
User Available
11
User Available
12
Onboard Mouse Port, if present, or user available
13
Reserved, Math Coprocessor
14
Primary IDE, if present, or user available
15
Secondary IDE, if present, or user available
Memory Map
Board Interrupts
