3–2

BIOS Setup Program

Main Menu Options

Sub Menu Options

AB Default

Description

System Date

Specifies the current date. Select the month from a popup menu.

System Time

Specifies the current time.

Floppy A:

Reports if diskette drive is connected to the system. No options.

Floppy B:

Reports if a second diskette drive is connected to the system.

Floppy Options

Floppy A: Type

1.44 / 1.25 MB,

3.5 inch

Disabled if Floppy

option not

selected

Specifies the physical size and capacity of the diskette drive. The
options are:

Disabled

360 KB, 5.25 inch

1.2 MB, 5.25 inch

1.44/1.25 MB, 3.25 inch

2.88 MB, 3.5 inch

Floppy B: Type

Disabled

Specifies the physical size and capacity of the diskette drive. The
options are:

Disabled

360 KB, 5.25 inch

1.2 MB, 5.25 inch

1.44/1.25 MB, 3.25 inch

2.88 MB, 3.5 inch

Hard Disk Type

Auto Configured

Manually configure the hard drive or have the system auto configure it.

User Definable

Auto Configured

If you select User Definable, the Number of Cylinders, Number of
Heads, and Number of Sectors can be modified.

Number of Cylinders

Auto Configured

If Hard Disk Type is set to User Definable, you must enter the number
of cylinders. If Hard Disk Type is set to Auto Configured, the number of
cylinders is displayed (read only field).

Number of Heads

Auto Configured

If Hard Disk Type is set to User Definable, you must enter the number
of heads. If Hard Disk Type is set to Auto Configured, the number of
heads is displayed (read only field).

Number of Sectors

Auto Configured

If Hard Disk Type is set to User Definable, you must enter the number
of sectors. If Hard Disk Type is set to Auto Configured, the number of
sectors is displayed (read only field).

Maximum Capacity

Displays the maximum capacity of your hard disk (read only field). It is
calculated from the number of cylinders, heads, and sectors.

Hard Disk C, D, E, F

IDE Translation Mode

Auto Detected

Specifies the IDE translation mode. The options are:

Standard CHS (less than 1024 cylinders)

Logical Block

Extended CHS (more than 1024 cylinders)

Auto Detected (BIOS detects IDE drive support for LBA)

Important: Do not change this option after the hard drive has been
formatted. Data may be corrupted.

Multiple Sector Setting

Auto Detected

Sets the number of sectors transferred by an IDE drive per interrupt
generated. The options are:

Disabled

4 Sectors/Block

Auto Detected

Check the specifications for your hard disk drive to determine which
setting provides optimum performance.

Fast Programmed I/O
Modes

Auto Detected

Sets how fast transfers on the IDE interface occur. The options are:

Disabled

Auto Detected

If set to disabled, transfers occur at less than optimized speed.
