3–6

BIOS Setup Program

Advanced Menu

Options

Sub Menu Options

AB Default

Description

Advanced Power
Management

Disabled

Enables or disables the Advanced Power Management (APM) in BIOS.
If disabled, none of the fields in the APM subscreen are displayed.

Power
Management

IDE Drive Power Down

Enabled

Enables or disables the IDE drives to power down when the system goes
into a power managed mode.

Management
Configuration

Inactivity Timer

10 minutes

Sets how long the system must be inactive before it enters the power
managed mode. The range is 0 to 255 minutes.

Hot Key

Sets the hot key that, when pressed while holding down the and
keys, causes the system to enter the power managed mode.

Configuration Mode

Use ICU

Sets how BIOS gets information about ISA cards that do not have Plug
and Play capabilities. The options are:

Use Setup Utility

Use ICU (ISA Configuration Utility)

Boot with PnP OS

Windows 95

Enables PC boot with an operating system capable of Plug and Play
add-in cards. The options are:

None

Other

Windows 95

Plug and Play
Configuration

ISA Shared Memory
Size

Disabled

Enables you to “unshadow” a block in upper memory. The options are:

Disabled

16 KB

32 KB

48 KB

80 KB

96 KB

If disabled, the ISA Shared Memory Address will not be visible.
Shadowing is a technique that copies a block of memory from an add-in
card’s ROM to the same address in system memory for faster access.

Important: This field should only be set to enabled when a non Plug
and Play ISA card that requires non-ROM memory space is installed.
For example LAN cards with on-board memory buffers and video capture
cards with video buffer memory.

IRQ 5, 9, 10, 11

Available

If Use Setup Utility (under Configuration Mode) is selected, this option
sets the status of the IRQ. The options are:

Available

Use By ISA Card

The PCI auto-configuration code looks here to see if these interrupts are
available for use by a PCI add-in board. If an interrupt is available, the
PCI auto-configuration can assign the interrupt used by the system. If
the system contains an ISA agent that uses one of these interrupts,
select used By ISA Card for that interrupt.

Note: IRQ 3, 4, 5, and 7 may not be available for this option, depending
upon the setting chosen for the COM1, COM2 and parallel ports in the
Peripheral Configuration Subscreen.
