Appendix E: Product Specifications
45
Publication 6185-UM003C-EN-P
Appendix
Appendix
Appendix
Appendix E: Product
: Product
: Product
: Product
Specifications
Specifications
Specifications
Specifications
Display
6185-H
6185-J and 6185-K
Type
Active Matrix Color Thin Film Transistor (TFT) LCD
Backlight
Type
Life Expectancy
Field Replaceable
Cold Cathode Tubes (CCT) (2 bulbs)
50,000 hours (mean for 1/2 brightness point)
Yes
Cold Cathode Tubes (CCT) (4 bulbs)
25,000 hours (mean for 1/2 brightness point)
Yes
Nominal Display Area
Diagonal
Horizontal
Vertical
15 in. (380 mm)
12 in. (304 mm)
9.0 in. (228 mm)
17.0 in. (432 mm)
13.3 in. (388 mm)
910.6 in. (270 mm)
Resolution
1024x768 x RGB pixels, 256K colors
1280x1024 x RGB pixels, 16.7m colors
Viewing Angle (CR
≥ 5)
Horizontal (typical)
Vertical (typical)
+/-60 deg.
+55/-45 deg.
+/-80 deg.
+/-80 deg.
Luminance (typical)
200 nit, 58 fL (screen overlay option will reduce
luminance)
170 nit, 50 fL (screen overlay option will reduce
luminance)
Contrast Ratio (typical)
250:1
200:1
Response Time
25 msec (typical)
40 msec (typical)
Video
6185-H
6185-J and 6185-K
Supported Standards
720x400 at 70Hz (VGA text)
640x480 at 60Hz and 75Hz
800x600 at 60Hz and 75Hz
1024x768 at 60Hz and 75Hz (native)
720x400 at 70Hz (VGA text)
640x480 at 60Hz and 75Hz
800x600 at 60Hz and 75Hz
1024x768 at 60Hz and 75Hz
1280x1024 at 60Hz and 75Hz (native)
Video Input Signal
RGB analog (white level = 0.714V above ref. Black, into 75 Ohms
Sync Input Signals
H and V separate (TTL levels, positive or negative)
Input Connection
HD-15
Controls and Indicators
6185-H
6185-J and 6185-K
Front Panel
Auto Adjustment, Status LEDs, OSD Control, Brightness
OSD Menu
Coarse/Fine, Position, Color Control, Reset, Language, Menu Display Time, Menu Position, Image
Effect
Keypad can be disabled from the rear of the monitor. See page 19.
Operator Input
Touchscreen Option - Resistive touchscreen, with serial controller and DOS drivers. Other OS
drivers are available.
