13–12 Keypad Configuration Utility Software
Publication 6180-6.0
The window titled KIC Keypad Configuration is the configuration stored
on the KIC card. If this window and all other keypad configuration
windows are closed, you can reopen the KIC Keypad Configuration from
the File menu.
To reopen the keypad configuration stored on the KIC card:
Choose Open KIC Keypad Configuration from the File menu.
A window opens with the KIC Keypad Configuration displayed in the
title bar.
Selecting Keys
The table below shows how to select keys on the keypad. You must
select a key before you enable/disable a key or redefine its function.
To Select: Do This: The result is:
Single key Click the left mouse
button on the key. The selected key is
highlighted with
handles.
Group of keys Click the left mouse
button and drag the
selection rectangle
around the keys you
want to select. The selected key is
highlighted with
handles.
All keys Choose Select All Keys
from the Edit menu. All keys are highlighted
and appear with
handles.
All Programmable Keys Choose Select All
Programmable Keys
from the Edit menu. All programmable keys
are highlighted and
appear with handles.
Multiple Keys Click the left mouse
button while holding
down the Ctrl key. The selected keys are
highlighted and appear
with handles.
Enabling and Disabling Keys
You can enable/disable all or specific keys on the keypad. By default, all
keys are initially enabled.
Note:
If the jumper P1 on the KIC board is in the non-default
position 1-2 (see page XX), all keypad keys are hardware
disabled.
