A–B
6
Chapter
6–1
Operating Procedures
This chapter describes most of the operations normally used in the set-up and
maintenance of a network. It also includes descriptions of some methods
used in discerning correct operation. Some of these are:
•
verifying proper operation
•
removal of a Master or Submaster from the network
•
changing a workstation into a Master
•
removal of a Normal workstation from the network
•
adding a Normal workstation to the network
Default Configuration – The major factory default settings are:
Parameter Value Configuration Menu
Terminal Number: 0 Network . . . . . . . . . . . . . . . . . . . . .
Host Port: COM Network . . . . . . . . . . . . . . . . . . . . . . . .
Terminal Type: Normal Network . . . . . . . . . . . . . . . . . .
Lower Poll Address 1 Network . . . . . . . . . . . . . . . . . . . .
Upper Poll Address 99 Network . . . . . . . . . . . . . . . . . . .
Offline Cycle 40 Network . . . . . . . . . . . . . . . . . . . . . . . .
Max Net Retries 10 Network . . . . . . . . . . . . . . . . . . . . . .
Comm Port Mode: Polled Network . . . . . . . . . . . . . . . .
Comm Baud Rate: 9600 Comm Port . . . . . . . . . . . . . . . . . .
Comm Data Bits: 7 Comm Port . . . . . . . . . . . . . . . . . . . . . .
Comm Parity: Even Comm Port . . . . . . . . . . . . . . . . . . . .
Comm Stop Bits: One Comm Port . . . . . . . . . . . . . . . . . . .
Comm CRLF: Disabled Comm Port . . . . . . . . . . . . . . . . .
Comm Echo: Disabled Comm Port . . . . . . . . . . . . . . . . . .
Sync Count: 0 (Remains 0 always) Comm Port . . . . . . . . .
Aux Baud Rate: 9600 Comm Port . . . . . . . . . . . . . . . . . . . .
Aux Parity: Even Comm Port . . . . . . . . . . . . . . . . . . . . . .
Aux CRLF: Disabled Comm Port . . . . . . . . . . . . . . . . . . .
Aux Echo: Disabled Comm Port . . . . . . . . . . . . . . . . . . . .
Comm Menu Char.: None Comm Port . . . . . . . . . . . . . . . .
Menu Password 0 System . . . . . . . . . . . . . . . . . . . . . . .
Clock Mode 7 System . . . . . . . . . . . . . . . . . . . . . . . . . .
File Block Size 256 System . . . . . . . . . . . . . . . . . . . . . .
Bar Code Symbology Code 3 of 9 Enabled Bar Code . . . . .
all others Disabled
The workstation will be reset to these settings when Option H – Reset to
Factory Defaults is selected from the Diagnostics Menu (Menu 6)
Chapter Objectives
