F Appendix
F–1
Converting from Incandescent to LED Lamps
This appendix describes how to convert the RediPANEL modules from
incandescent to LED illumination.
To replace the incandescent bulb with an LED lamp for an 800A
RediPANEL module, order the lamp upgrade kit.
For this module: Order:
32 Operator Modules Catalog No. 2705-NLU1
16 Operator Modules Catalog No. 2705-NLU2
8 Operator Modules Catalog No. 2705-NLU3
Replace the existing circuit board with the board provided in the kit.
Instructions are provided with the kit.
You must purchase the LEDs separately.
For these LEDs: Order:
12 VDC Red LEDs Catalog No. 800T-N61R
12 VDC Green LEDs Catalog No. 800T-N61G
12 VDC Amber LEDs Catalog No. 800T-N61A
To convert an 800T/H RediPANEL from incandescent bulbs to LED lamps,
you must have a 120 VAC transformer style power module. Order as follows:
For these LEDs: Order:
Red LEDs Catalog No. 800T-N318R
Green LEDs Catalog No. 800T-N318G
Amber LEDs Catalog No. 800T-N318A
LED Lamp Upgrade
