Chapter 2
Configuring the RediPANEL Module
2–2
Table 2.A lists the rack size requirements for an 8, 16 or 32 button
RediPANEL module. The rack size varies depending on the number of push
buttons and the functions used.
Table 2.A
Rack Size Requirements for 8, 16, and 32 Button RediPANEL Modules
Number
o Buttons
Handshake
L g ted
Lighted
Num er
of Buttons
No Yes
Lighted
Lighted
and Flashing
8 n
n
1 4
16 n
1/4
1
n
1
32 n
1/2
3
n 1/2 3/4
You can ignore the I/O requirements in the table and specify a full rack by
setting switch 6 in DIP Switch Bank 2 on the RediPANEL. A full rack is
automatically reserved in the Input/Output Image Tables of the processor.
