Appendix
A–1
Specifications
Electrical
Built-in Power Supply 90 to 264V AC, 47-63 Hz
18 to 30V DC
Input Current and Power Ratings
32 Buttons 16 Buttons 8 Buttons On/Off
D Input
2.1A, 50VA 1.25A, 30VA 0.83A, 20VA All On
24V DC Input
0.83A, 20VA 0.58A, 14VA 0.46A, 11VA All Off
A Input
550 mAmps 360 mAmps 260 mAmps All On
120V AC Input
260 mAmps 190 mAmps 135 mAmps All Off
Lamps 12V DC, Catalog No. 800M-N16
LEDs 12 Volts, Catalog No. 800T-N61R (Red)
-N61G (Green)
-N61A (Amber)
Communications Connector Standard 3-prong female connector
(supplied with each module as Part No. 22112-046-03)
UL File / Guide Non-hazardous Locations: E56639 / NMTR
Hazardous Locations: E10314 /N01V ➀
CSA Non-hazardous Locations: LR62923 ➀
Hazardous Locations: LR11924
Mechanical
Enclosure NEMA Type 13
Configurations
8 Push Button Module 4 red, 4 green backlit buttons
16 Push Button Module 6 red, 6 green, 4 amber backlit buttons
Module is also available with membrane buttons:
4 rows of 4 buttons with LED output indicators
32 Push Button Module 8 red, 8 green, 8 amber, 8 clear (white) backlit buttons
Replacement Illuminated Push Button
8, 16 Push Button Units Catalog No. 800A-C2D 1
32 Push Button Units Catalog No. 800A-C2C 12
Dimensions
Length 9.25 inch (234.95 mm)
Height 7.00 inch (177.8 mm)
Depth 6.88 inch (174.75 mm)
Weight 9 lbs. (4.1 kg)
➀ Hazardous location RediPANELs approved for Class 1, Division 2, Group A, B, C, and D applications.
RediPANEL 800A Module
