Nema type 4x membrane push button modules – Rockwell Automation 2705 RediPanel Push Button Module User Manual
Page 12
Chapter 1
Overview
1–5
Unpopulated Configuration
You can order an unpopulated 800T/800H RediPANEL module. The
unpopulated configuration consists of the enclosure and electronics without
the 800T or 800H devices. Each 800H/T device is ordered separately.
!
ATTENTION: Only install Allen-Bradley 800T or 800H
devices in the RediPANEL. Using operators from other
manufacturers voids the warranty.
The NEMA Type 4X Membrane Push Button Module has a standard
configuration of 4 rows of 4 buttons. Each button has an LED in the upper
right corner. These LEDs perform the same function as the lamp on the
standard push button modules.
The module comes with five different color inserts to legend each button
location. The inserts are coated mylar stock for writing (ink, pencil, or
marker), typing, or printing a legend.
NEMA Type 4X Membrane
Push Button Modules
