18 VersaView 6181H Integrated Display Computers
Publication 6181H-IN001B-MU-P
Mechanical
Weight
10 kg (23 lb)
Dimensions, Overall (H x W x D)
309 x 410 x 109 mm (12.17 x 6.14 x 4.29 in)
Cutout Dimensions (H x W)
285 x 386.6 mm (11.24 x 15.22 in)
Environmental
Operating Temperature
0…50 °C (32…122 °F)
Storage Temperature
-20…60 °C (-4 to 140 °F)
Relative Humidity
10%…90% without condensation
Shock, Operating
15 g (1/2 sine, 11ms)
Shock, Non-operating
30 g (1/2 sine, 11ms)
Vibration, Operating
1 g Peak (10…500Hz)
Vibration, Non-operating
2 g Peak (10…500Hz)
Electrical
Input Voltage, AC
90…264V ac, autoranging
Line Frequency
47…63 Hz
Power Consumption, AC
100 VA (1.0 A @ 100V rms, 0.42 A @ 240 V rms)
Agency Certifications
CE marked for all applicable directives
UL 60079-15 Recognized Component, C-UL
Certified
LVD (73/23/EEC)
EMC (89/336/EEC)
C-Tick
Class
I
, Division 2, Class
I
, Zone 2
Specifications
