VersaView 6181H Integrated Display Computers 17
Publication 6181H-IN001B-MU-P
Network Connections
VersaView computers accommodate CAT5 twisted pair Ethernet cabling with RJ45
connectors to support 100 Mbps network data transfer.
Battery Information
The computer contains a battery to maintain CMOS settings and the real-time clock.
The battery is located in a battery holder on the computer’s motherboard.
Specifications
IMPORTANT
Performance degradation of your Ethernet communications is
likely to result if the unit or cables are subjected to extreme
radiated or conducted high-frequency noise. It is the user’s
responsibility to properly route cables and condition input power
in order to improve communication reliability.
Proper cable routing and power conditioning is required to ensure
reliable Ethernet communications in industrial environments.
Rockwell Automation recommends that all Ethernet cabling be
routed through dedicated metal conduits. Installing ferrite bead
filters at cable ends may also improve reliability.
WARNING
Do not dispose of battery in a fire or incinerator. Dispose of
used batteries in accordance with local regulations or manufac-
turer’s instructions.
Specifications
Display
Display Description Active Matrix Color TFT
Display Size 15.0 inch
Display Area 305 x 229 mm (12 x 9 in)
Resolution 1024 x 768, 256K Color
Response Time 15 ms (typical)
Touchscreen (optional) Resistive antiglare
