Rockwell Automation 6181 Industrial Computer User Manual
Page 129

CPU Specifications and BIOS Settings
B–5
Publication 6181-UM001D-EN-P
ADVANCED
Tab
Backlight Timeout
15 minutes
(options are disabled, 30 seconds, 1 minute, 2
minutes, 4 minutes, 6 minutes, 8 minutes, 12
minutes, and 15 minutes)
PCI/PNP ISA DMA Resource Exclusion – all
available
PCI/PNP IRQ Resource Exclusion – all
available
PCI Configuration
(allows
user to reserve specific
resources for ISA card)
PCI/PNP ISA UMB Region Exclusion – if
KTCX15 then D000-D3FF Reserved, Not
Shadowed. Otherwise, all available
I/O Device Configuration
Serial Port A
Auto
Serial Port B
Auto
Mode
Normal
Parallel
Port
Auto
Mode
Bi-directional
Floppy
Disk
Controller
Enabled
(Use this
setting to disable the
RAC6181 floppy
diskette drive)
PS/2 Mouse
Auto Detect
Reset Configuration Data
No
Large Disk Access Mode
DOS
Secured Setup
Configurations
No
Memory Parity Check
ECC
DMI Event Logging
View DMI event log
Enter
Event
Logging
Enabled
Mark DMI events
as read
Enter
Clear all DMI event
logs
No
Installed O/S
Other
HARDWARE
Tab
Enable Voltage Reading
Yes
3.3 Volts:
3.17 to 3.43
5 Volts:
4.75 to 5.25
12 Volts:
11.4 to 12.6
-5 Volts:
-4.25 to –5.75
-12 Volts:
-10.8 to –12.35
Enable Fan Speed
Yes
System Fan
2520 RPM minimum
Enable Temperature
Yes
Temperature 60C
maximum
