Page 13: Chapter
Chapter
2
Publication 2755-6.13
Hardware Features
This chapter describes the features of the StrataScan Bar Code
Readers (Catalog Nos. 2755-LHR-5B, 2755-LHR-3C, 2755-LHR-5C
and 2755-LHR-5BX1) and interface box (Catalog No. 2755-LHB-1).
Included are descriptions of:
•
reader features
•
interface box features
•
decoding
•
safety information
•
scan beam options
•
accessories
The reader features are shown below.
Scan Window
Ports
Speaker
LEDs
Mounting
Bracket
Reader Features
