T YPICAL USES
„
Rotate a resource picture to 180 degrees at a rate of 5 degrees per second
P ROMPTS
Data modules
Data modules are the set of objects in the spreadsheet view of the model that define the
characteristics of various process elements, such as resources and queues.
Advanced Set module
D ESCRIPTION
The Advanced Set module specifies queue sets, storage sets, and other sets and their
respective members. A set defines a group of similar elements that may be referenced via
a common name and a set index. The elements that make up the set are referred to as the
members of the set.
Queue sets may be specified within a Seize or material-handling-type module. Storage
sets may be used in the Store and Unstore module. Other sets may include sets of
attributes or other miscellaneous elements.
Prompt Description
Name Unique module identifier. This name is displayed on the module shape.
Variable Type Specifies the array characteristics of the variable being adjusted.
Row Specifies the row index if the variable is an array.
Column Specifies the column index if the variable is a 2-D array.
Variable Name Specifies the name of the variable to adjust.
To Value Specifies the target value that the variable will be adjusted to.
Rate Specifies the rate at which the adjustment will be made.
Units The time units of the rate.
Update Interval Specifies the interval between updates of the variable’s value as the
variable is adjusted at the specified rate.
Units The time units of the update interval.
Allocation Type of category to which the entity’s incurred delay time and cost in the
module will be added.
