A RENA U SER ’ S G UIDE
108
• •
•
•
•
Release Regulator module
D ESCRIPTION
The Release Regulator module is used to release tank regulators that have been allocated
to an entity using the Seize Regulator module. This makes those regulators available to
other entities waiting to seize the regulator(s).
When the entity enters the Release Regulator module, it gives up control of the specified
regulator(s). Any entities waiting in queues for those regulators will gain control of the
regulators immediately.
T YPICAL USES
„
Releases control of a regulator. A regulator is a device that adds or removes material
from tank (e.g., a valve).
P ROMPTS
Rule Number Specifies number argument that is passed to the UserRule routine.
Attribute Name Name of the attribute that stores the name of the regulator to seize.
Expression Expression that evaluates to the name of the regulator to seize.
Prompt Description
Name The module identifier.
Regulators:
Regulator Type Indicates how the regulator to release will be specified; defined as
Regulator, Regulator Set, Attribute, Expression.
Regulator Name Name of the regulator to release.
Regulator Set Name Name of the regulator set that contains the regulator to release.
Release Rule Method of determining which regulator within a set to release. Last
Member Seized and First Member Seized will release the last/first
member from within the set that was seized. Specific Member indicates
that a member number or attribute (with a member number value) will
be used to specify the member to release.
Set Index Index into the regulator set.
Prompt Description
